923853.0103 923853.0106 Kalmar top lift spare parts
923853.0103 923853.0106 Kalmar top lift spare parts for sale:
1. We supply both original and aftermarket products for you
2. From the manufacturer to the customer directly, saving your cost
3. Stable stock for normal parts
4. In Time Delivery Time, with competitive shipping cost
5. Professional and on time after service
描述
923853.0103 923853.0106 Kalmar top lift spare parts for sale:
Product introduction:
The Kalmar reach stacker RS DRF450 spare parts and lifting/lowering spare parts.
Product advantages:
1. High-requirement quality management.
2. Use high-quality materials.
3. More accurate matching size.
4. Reduce the risk of damage.
5. Factory direct sales, price discount.
Details of 923853.0103 923853.0106 Kalmar top lift spare parts:
923853.0103 Aggregate KPL
– 923855.1621 Top lift
1 – 923855.1616 Beam
2 – 923855.1617 Side shifting frame
3 – A24057.0200 Side shifting cylinder
4 – 924015.0592 Shaft
5 – 2583 Retaining ring
6 – 923863.7803 Lock ring
7 – 923857.0070 Bearing
8 – 924015.0611 Bracket
9 – 923828.0747 Spacer ring
10 – 920076.007 Nut
11 – 98154 Washer
12 – 923855.1618 Spacer ring
13 – 923855.1619 Screw
14 – 920098.009 Washer
15 – 923863.7378 Screw
16 – 923855.1124 Slide plate
17 – 923855.0897 Cover
18 – 923855.0989 Spacer
20 – 923855.1772 Slide plate TJ=20
21 – 923855.1114 Lock nut
22 – 923855.1115 Screw
23 – 923855.0902 Pin
24 – 923855.1116 Bearing
25 – 923855.0903 Lock nut
26 – 923855.1117 Lock washer
27 – 923855.0906 Shaft
28 – A22273.0100 Pull rod
29 – 923855.1120 Beam
30 – A22274.0100 Spacer
31 – 923828.0829 Screw
32 – 923933.0424 Nut
33 – 98150 Washer
34 – 923855.1791 Screw
35 – 923855.1620 Spacer plate
36 – 920099.065 Screw
37 – 923941.0142 Lock washer
55 – 923855.1118 Spacer
– 923110.0360 Lubricating grease CARTRIDGE
0,65KG
– 923595.0003 Lubricating grease CAN 5,0KG
923853.0106 Aggregate KPL
– 923941.0376 DRAWING
1 – 923855.1146 Beam
4 – 923855.1147 Side shifting frame
5 – 923976.2404 Mounting
6 – 923855.1771 Side shifting carriage
10 – 924015.0182 Cylinder
11 – 924015.0592 Shaft
12 – 923863.7795 Lock ring
13 – 923863.7803 Lock ring
14 – 923828.0747 Spacer ring
15 – 923828.0721 Bearing
20 – 923828.0991 Plate
21 – 923110.0701 Screw
22 – 923872.0392 Washer
advantage
CCMIE Group started to sell spare parts for XCMG, Shantui, SANY, Kalmar, SDLG， Komatsu, and Cummins engines in 2011. We have established four spare parts warehouses in Xuzhou, Jining, Kunshan, and Changsha in China, providing customers worldwide with a wide variety of high-quality spare parts. Our spare parts system can provide you with accurate and competitive prices in the shortest possible time. We are confident that we will become your excellent business partner!
1. As accessories’ prices fluctuate wildly, please consult us for details such as specific prices and shipping costs!
2. There are many kinds of accessories, which cannot be displayed one by one. We can find the correct accessories if you have the accessory part number/accessory nameplate/picture/machine nameplate!
3. We have a large inventory of commonly used spare parts in our warehouse, which can be delivered within three days!
Our company also supplies the four-wheel area of the chassis parts of bulldozers and excavators. The products are as follows:
(1) Shantui four-wheel area: Shantui guide wheel, Shantui drive wheel, Shantui support sprocket, Shantui drive wheel, Shantui tension, Shantui professional oil, Shantui sprocket tooth block, Shantui knife Angles, Shantui blades, Shantui construction machinery bolts, Shantui chain rails, Shantui track shoes, Shantui bucket teeth.
(2) Four-wheel belt: PC60. pc100. pc120, PC130. PC200, pc220. pC300. PC360. Pc400 series excavator driving wheels, guide wheels, tug wheels, driving teeth, tensioning devices, and chains.
(3) Yuchai four-wheel area: Yuchai yc85 driving wheel, Yuchai yc85 supporting wheel, Yuchai yc85 tensioning device, Yuchai 55 guiding wheel, Yuchai yc55 driving wheel, Yuchai yc55 tensioning device.
(4) Kobelco four-wheel area: Kobelco sk200-3 driving wheel, Kobelco 200-6 supporting wheel, Kobelco 200-3 supporting wheel, Kobelco 200-6 driving wheel.
(5) Sumitomo four-wheel area: Sumitomo 120 driving wheels, Sumitomo 200 driving wheels, Sumitomo 200 supporting wheels.
(6) Carter’s four-wheel area: Carter driving wheels, Carter supporting wheels, Carter guiding wheels,
(7) Doosan four-wheel area: Doosan dh55 driving wheels, Doosan dh220 driving wheels, Doosan dh220 supporting wheels.
(8) Three-one four-wheel belts: Three-one sy130 supporting wheels, three-one sy130 driving wheels, three-one 300 supporting wheels, and three-one 300 driving wheels.
Product Quick Navigation | ||||
FAQ
Q1: What payment methods can you accept?
T/T, Western Union, PAYPAL, Bank of China, HSBC
Q2: Can you pack me according to my request? How is the product packaged?
Yes, it is exported in neutral packaging in wooden or cardboard boxes.
Q3: What is the delivery time?
1) Spot: usually 3-5 days. It can be as fast as 24 hours.
2) Out of stock: According to the quantity you require, it usually takes 10-20 days, but we have a large amount of inventory.
Q4: What kind of transportation can you provide?
1) Large quantities of orders: sea or air freight. (We can give you the best price)
2) Small batch orders: DHL, TNT, UPS, FedEx, EMS, ARAMEX
Q5: Do you accept small orders?
Yes, small orders can be accepted.
Q6: What products can your company provide?
1) CCMIE brand hydraulic pump valves and other products, OEM, 100% genuine parts, COPY (made in China).
2) Genuine spare parts.
