Electric Balance Forklift XCB-L18/P18 For Sale
1.8ton XCB-L18/P18 electric forklift features the breakthrough to the limitations of the style design in forklift industry with its unique and brand new structural appearance.
Load Capacity: 1800kg
Operating weight: 3200kg
Max. lift height: 3000mm
Power mode: Plumbic acid battery (XCB-P)/Lithium battery (XCB-L)
描述
Product Introduction
XCB-L18/P18 is a 1.8 ton electric counterbalance forklift.
Counterbalanced forklifts are the most widely used forklifts. The fork is outside the center line of the front wheel. In order to overcome the overturning moment generated by the goods, a counterweight is installed at the rear of the forklift. This kind of forklift is suitable for operation in the open-air freight yard. Generally, pneumatic tires are used, the running speed is relatively fast, and it has good climbing ability. When picking up or unloading goods, the gantry can be moved forward. Easy fork insertion, and the mast tilts back after picking up to keep the cargo stable during operation.
Main Parameters
Item | Unit | Parameter |
Load capacity | kg | 1800 |
Operating weight | kg | 3200 |
Max. lifting height | mm | 3000 |
Maximum travel speed (full load / no load) | km/h | 13/14 |
Maximum grade (full load / no load) | % | 15/17 |
Height when gantry retracts | mm | 1985 |
Remarks: This product is continuously improved with the progress of technology. The difference between the parameters and structural characteristics listed above is subject to the actual product.
Performance Characteristics
1. XXCB-L18/P18 electric balance forklift features the breakthrough to the limitations of the style design in forklift industry with its unique and brand new structural appearance.
2. The application of XEC electrical control matching technology provides multiple modes of speed selection for various different working conditions. Better elevating speed with new safety mode is design for easy and convenient operation. Through accurate electrical controlled adjustment, the integrated drive axle can achieve the gradeability up to 17%.
3. The application of XEC electrical control matching technology not only improves the smoothness of vehicle starting, acceleration and brake as well as the comfort of operation, but also enhance the protection of materials and personnel. The hydraulic system is applying dual-seal structure of 24° cone and O-ring, effectively preventing the system from any possible leakage. It is also using the most advanced sixth generation hydraulic cylinder to ensure the safety and reliability of operation.
4. The covering parts can be removable without any help of the tools, providing more space and convenience of maintenance.
5. On the basis of ergonomics, it is the first time in the industry configured with dual DOF (degree of freedom) steering control mechanism of independent intellectual property right to create a more comfortable experience of operation and control.
- All relevant spare parts for XCB-L18/P18 electric balance forklift are available.
